• CDI Digital Flexo Plate Making Machine

CDI Digital Flexo Plate Making Machine

Model NOMax Produce Capacity
ALD-940F-11.4 ㎡/h
ALD-940F-22.8 ㎡/h

Technical Parameters
Max. plate size940×675mm (37×26 inches)
Plate thickness0.15~3.94mm
Output mediaDigital flexographic water-washable letterpress plates;
Digital flexographic water-washable plates;
Digital flexographic solvent-washable plates;
Thermal(0.15mm) CTP plates;
Dry film
ApplicationLabel printing、Trade mark
Loading methodManual loading
InterfaceGigabit Ethernet
External dimension(mm)L×W×H=1425mm×980mm×1150mm, 750KG
Power supply220V AC 50/60Hz 5kW Peak (Single phase)
EnvironmentTemperature 18-30℃, Humidity 40-70% non condensing
Products Details

1.Max plate size 940*675mm(60*50inch)

2.Thickness of plate 0.15-3.94mm

3.Output Media: Output Media: Digital flexographic water-washable letterpress plates;Digital flexographic water-washable plates; Digital flexographic solvent-washable plates; Thermal(0.15mm)CTP plates

4.Main application Label, Trademark

5.Resolution 4000DPI

6.Loading Method: Manual Loading

7.Interface: Gigabit Ethernet

8.Size of machine: L×W×H=1425mm×980mm×1150mm,750kg

9.Power: 220VAC 50/60Hz 7kW Peak

10.Environment: Best environment temperature 18-30℃,  Humidity 40-70% non condensing

Why Choose Us
our advantages
our advantages

1. One-stop purchasing, all products related to flexographic printing can be purchased from our company

2. With our own 3 plate making factories, we can provide customers with all flexo printing solutions including factory founding, design, plate


Customized products and packaging are welcomed,aolide can help you to build your own brand and also can help you  to make your innovations to actual products

After sales support
After sales support

1. Feedback fast

2.There are professional engineers and after-sales personnel to provide customers with services and solutions
